Taramps ‘Smart’ Mono Block Amplifier, 3000W RMS

DUAL FAN COOLED – SMART3 CLASS D MONO BLOCK AMPLIFIER, 3000 WATTS RMS

1 X 3000 WATTS RMS @ 1 OHM – 12.6 VDC
1 X 3000 WATTS RMS @ 2 OHM – 12.6 VDC
1 X 2000 WATTS RMS @ 4 OHM – 12.6 VDC
DIMENSIONS (H X W X D) 7″ X 2.8″ X 9.4″

RECOMMENDED FUSE: 150A EXTERNAL FUSE (NOT INCLUDED)

CLASS D
1 OHM / 2 OHM STABLE
INPUT SENSITIVITY : 0.22V ~ 4V
SIGNAL TO NOISE RATIO : >90DB
FREQUENCY RESPONSE : 10HZ – 10KHZ (-3DB)
HIGH PASS CROSSOVER (HPF) : 10HZ – 90HZ
LOW PASS CROSSOVER (LPF) : 90HZ – 10KHZ
BASS BOOST FREQ.: 35HZ – 55HZ (BOOST: 0 ~ +10DB)
RCA IN/OUTPUTS
EFFICIENCY : 79%
INPUT IMPEDANCE : 10K OHMS
WORKS WITH M1 – SOLD SEPARATELY
PROTECTION: OUTPUT SHORT CIRCUIT, LOW / HIGH VOLTAGE PROTECTION AND THERMAL PROTECTION

• MULTI-IMPEDANCE: FEATURING NEW CONTROL TECHNOLOGY AND NEW FUNCTIONS, THE SMART 3 BRINGS 3000W RMS RATED POWER IN THE RANGE OF 1 TO 2 OHMS: (1 – 1.33 – 1.5 – 1.67 AND 2 OHMS WITH SAME POWER)
• SMART LEDS: LEDS OUTPUT SIGNAL LEVEL INDICATOR ON TOP OF PRODUCT;
• RCA INPUT FOR UP TO 4V RMS: INPUT GAIN ADJUSTMENT THAT ALLOWS HEAD UNITS UP TO 4VRMS OUTPUT LEVEL
• DUAL RCA IN / OUT INPUT: RCA CONNECTOR WITH INPUT AND OUTPUT FUNCTION, ELIMINATES THE NEEDING OF “Y” CABLES FOR SEND THE SAME INPUT SIGNAL TO ANOTHER AMPLIFIER
• POWER CONNECTOR FOR CABLES UP TO 1/0 AWG: ALLOWS THE USE OF POWER CABLES WITH LARGER GAUGE (UP TO 50MM²) FOR HIGHER PERFORMANCE
• AUTO-RESTART PROTECTIONS: THE AMPLIFIER AUTOMATICALLY RESTARTS AFTER A PROTECTION EVENT
• RAMP AUDIO INITIALIZATION: AFTER TURNING ON THE AMPLIFIER, AUDIO IS RELEASED GRADUALLY (RAMP)

SKU SMART3 MANUFACTURER MODEL #SMART 3 UPC 7898556845205CASE QUANTITY1 BRAND: TARAMPS WEIGHT 5.75 LBS CARTON DIMENSIONS9 × 3 × 10 IN WATTS 3000

OHM STABLE 1

AMP CLASS D
